Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SOWAY
  • Model Number: SF11X series
  • Product name: PP signal/ multipoint vertical float level switch for various tanks
  • Material: P.P
  • Thread type: M8*1.25 or M10*1.5
  • Cortact form: Normally open, normally close or SPDT
  • Cable length: 350mm, also could be custom
  • Applications: Water, sewage, oil, fuel, coffee machine,
  • Maximum Load: 70W
  • Max Load Current: 1A
  • Operating temperature: -45 ~ +85 ℃
  • Output signal: switch output

Packaging & Delivery

Packaging Details Standard exporting package.Neutral box packaging, cartons and foam inside Corner, sponges and other protection, to ensure the safety of traffic.

 product name:  S.S. Float Level Switch



1.   INTRODUCTION

Magnetic float level switch principle is the float which link to rod equipped with a constant magnetic field, because of the liquid level rise or fall, make the float internal generated magnetic field, thus triggered  the reed switch which inner the rod wroking. Widely used in liquid level measurement, liquid level alarm and level security control field.



2.  FEATURES

2.1 No standby power requirement

2.2 Customer can defined activated range and connection

2.3 Enclosure material: stainless steel 304 or 316

2.4 High stability, high reliability, high consistency



3. APPLICATIONS

Level control, level measurement

Home appliance level detection

Water cooler, coffee machine, water dispenser, humidifier, etc

Container level detection



4. SPECIFICATION

Electrical Parameters

Model

1

2

3

Switched Power(max)

10W

70W

5W

Switched Voltage(max)(DC)

200V

200V

175V

Switched Voltage(max)(AC)

140 V

250V

125V

Switched Current(max)(DC)

500mA

1000mA

400mA

Switched Current(max)(AC)

500mA

1000mA

280mA

Breakdown Voltage(min)

250V DC

580V DC

200V DC

Carry Current(max)

1.0A

2.25A

0.5A

Contact  Resistance (min)

200mΩ

200mΩ

200mΩ

Insulation Resistance (min)

106MΩ

106MΩ

106MΩ

Operating Temperature

-40°C-+80°C

-40°C-+80°C

-40°C-+80°C





ENTIRE FILM

Q: What payment method your company accepts?

A: We accept T/T (Bank Transfer), L/C, Western Union and Paypal. If any other payment method is more convenient to you, please tell us by including a note while making payment.



DIREDT SELLING PRICE

Q: Can you do drop shipping?

A: Yes, we can help you ship the goods to any address you want. We will not put any catalogue or any document with our company info in it if you requested.



HIGH QUALITY QUALITY

Q: How long for the production time?

A: Normally in stock, or 7~10days depends on order quantity.



PACKING SPECIFICATION

Q: You said we can use our own logo? What's the MOQ if we wanna do this?

A: Yes, 100pcs MOQ



GOOD FAITH SERVICE

Q:How to contact you guys?

A:Skype ID:jack-soway B:Contact us by e-mail
